| 付属品 |
Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x ASUS WiFi Q-Antenna
1 x Cable ties package
1 x M.2 Q-Latch package
1 x M.2 Q-Slide package
1 x ROG key chain
1 x ROG Strix stickers
4 x M.2 rubbers
Documentation
1 x Quick start guide |
| その他I/Oポート詳細 |
［BACK PANEL I/O PORTS］
1 x USB 20Gbps port (1 x USB Type-C)
3 x USB 10Gbps ports (2 x Type-A + 1 x USB Type-C)
4 x USB 5Gbps ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x DisplayPort
1 x HDMI port
1 x Wi-Fi module
1 x Intel 2.5Gb Ethernet port
2 x Audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack button
1 x Clear CMOS button |
| LAN |
［ETHERNET］
1 x Intel 2.5Gb Ethernet
ASUS LANGuard
［WIRELESS & BLUETOOTH］
Wi-Fi 7
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band
Supports Wi-Fi 7 160MHz bandwidth、up to 2.9Gbps transfer rate.
Bluetooth v5.4 |
| USB |
［USB］
Rear USB (Total 10 ports)
1 x USB 20Gbps port (1 x USB Type-C)
3 x USB 10Gbps ports (2 x Type-A + 1 x USB Type-C)
4 x USB 5Gbps ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 7 ports)
1 x USB 10Gbps connector (supports USB Type-C)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports |
| 仕様1 |
［対応OS］Windows 11
［フォームファクター］ATX
［CPU］AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
［CHIPSET］AMD B850
［MEMORY］4 x DIMM slots、max. 192GB、DDR5
［AUDIO］ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| 仕様2 |
［GRAPHICS］
1 x DisplayPort(Supports max. 8K@30Hz as specified in DisplayPort 1.4)
1 x HDMI port(Supports 4K@60Hz as specified in HDMI 2.1) |
| 仕様3 |
［EXPANSION SLOTS］
AMD Ryzen 9000 & 7000 Series Desktop Processors
1 x PCIe 5.0 x16 slot with Q-Release Slim
AMD Ryzen 8000 Series Desktop Processors
1 x PCIe 5.0 x16 slot with Q-Rlease Slim (supports PCIe 4.0 x8 or x4 mode)
AMD B850 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)
［STORAGE］
4 x M.2 slots
2 x SATA 6Gb/s ports |
| 仕様 |
［INTERNAL I/O CONNECTORS］
Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power Related
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connector
Storage Related
4 x M.2 slots (Key M)
2 x SATA 6Gb/s ports
USB
1 x USB 10Gbps connector (supports USB Type-C)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x CPU Over voltage jumper
1 x Front Panel Audio header (F_AUDIO)
1 x Power button
1 x 10-1 pin Front System Panel header
1 x Thermal Sensor header
1 x Thunderbolt (USB4) header |
