| 付属品 |
Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x ASUS WiFi Q-Antenna
2 x M.2 rubber packages
1 x Screw package for M.2 SSD
1 x TUF GAMING sticker
Documentation
1 x Quick start guide |
| その他I/Oポート詳細 |
［Back Panel I/O Ports］
1 x USB 20Gbps port (1 x USB Type-C with DP Alt mode)
2 x USB 10Gbps ports (2 x USB Type-A)
3 x USB 5Gbps ports (3 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x DisplayPort
1 x HDMI port
1 x Wi-Fi module
1 x Realtek 2.5Gb Ethernet port
5 x Audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack button |
| LAN |
［Ethernet］
1 x Realtek 2.5Gb Ethernet
TUF LANGuard
［Wireless & Bluetooth］
Wi-Fi 7
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band
Supports Wi-Fi 7 160MHz bandwidth、up to 2.9Gbps transfer rate.
Bluetooth v5.4 |
| USB |
［USB］
Rear USB (Total 8 ports)
1 x USB 20Gbps port (1 x USB Type-C)
2 x USB 10Gbps ports (2 x Type-A)
3 x USB 5Gbps ports (3 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 5 ports)
1 x USB USB 10Gbps connector (supports USB Type-C)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
1 x USB 2.0 header supports 2 additional USB 2.0 ports |
| 仕様1 |
［対応OS］Windows 11 (22H2 & later)
［フォームファクター］ATX
［CPU］Support Intel Core Ultra Processors(Series 2) 、LGA1851
［Chipset］Intel B860
［Memory］4 x DIMM slots、max. 256GB、DDR5
［Audio］Realtek 7.1 Surround Sound High Definition Audio CODEC |
| 仕様2 |
［Graphics］
1 x DisplayPort(Supports max. 4K@60Hz as specified in DisplayPort 1.4.)
1 x HDMI port(Supports 4K＠60Hz as specified in HDMI 2.1.)
1 x USB 20Gbps port (USB Type-C) supports DisplayPort video output(Supports max. 4K＠60Hz as specified in DisplayPort 1.4.) |
| 仕様3 |
［Expansion Slots］
Intel Core Ultra Processors(Series 2)
1 x PCIe 5.0 x16 slot
Intel B860 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)
1 x PCIe 4.0 x1 slot
［Storage］
3 x M.2 slots
4 x SATA 6Gb/s ports |
| 仕様 |
［Internal I/O Connectors］
Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power Related
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connectors
Storage Related
3 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 10Gbps connector (supports USB Type-C)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
1 x USB 2.0 header supports 2 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Clear CMOS header
1 x Chassis Intrusion header
1 x COM Port header
1 x Front Panel Audio header (F_AUDIO)
1 x 10-1 pin Front System Panel header
1 x Thunderbolt (USB4) header |
